Server Dell XE9680 8x2.5" NVMe with 2x Platinum 8480+, 2TB RAM, BOSS-N1 card with 2x480GB SSD NVMe M.2, 8x 3.84GB SSD NVMe U.2 2.5", 8x H100 SXM5 80GB, 2x1GbE LOM, 2x10/25GbE SFP28 OCP 3.0, 2x100GbE QSFP56, 8x 1x400Gb/s NDR, 6xPSU, rails, iDRAC9
Manufacturer: Dell
PN: XE9680-8x2.5-V01
Warranty: 36 months with the possibility of extension
This set contains:
- 1x Dell PowerEdge XE9680 8x2.5" NVMe server platform
- 2x Intel Xeon Platinum 8480+ 56-core 2GHz 105MB 350W processor
- 32x RAM 64GB 4800MHz DDR5 RDIMM
- 1x BOSS-N1 card
- 2x 480GB SSD NVMe M.2 hard drive
- 8x 3.84TB SSD NVMe U.2 2.5" hard drive
- 8x 2.5" drive tray
- 8x NVIDIA H100 SXM5 80GB vRAM graphic card
- 1x 2x1GbE NDC network card
- 1x 2x10/25GbE SFP28 OCP 3.0 network card
- 1x 2x100GbE QSFP Adapter network card
- 8x 1x400GbE QSFP56-DD Adapter network card
- 6x Dell power supply
- 1x Rail kit
Technical information about the Dell PowerEdge XE9680 server
- Server height: 6U
- Server depth: 101cm
- Maximum server weight: 114kg
- Enclosure types: 8x2.5" or 16xEDSFF E3.S Gen5
- Number of processors: maximum 2 x CPU 4th or 5nd Generation Intel Xeon Scalable processors
- Maximum number of processor cores: 2x 56-core / 112-thread CPU total 56-core / 112-thread Gen4 or 2x 64-core / 128-thread CPU total 128-core / 256-thread Gen5
- Number of RAM memory banks: 32 DDR4 DIMMs
- Maximum RAM size: 32x128GB DDR5 RDIMM up to 4TB
- Maximum disk size: 8x2.5" or 16xEDSFF E3.S Gen5
- Motherboard chipset: Intel C741
- Number of USB ports: 3 (1x front, 2x rear)
- Number of PCI-E slots: up to 10x PCI-E
- Maximum number of power supplies: 6
- Supported power supplies: 2800W, 3000W or 3200W
- Remote management: iDRAC 9
- Supported internal controllers: PERC S160, H965i
Optional accessories for the XE9680 server
- Front panel / bezel / bezel
- Power cables
- PCI-E expansion cards
- Stabilizing feet
All additional accessories you will find in our offer.
Together with the server it is possible to purchase the operating system
- Windows Server Standard
- Windows Server Essentials
- Windows Server Data Center
- VMWare (ESXi, vSphere, vSAN)
- other software such asSQL Server
When you buy this server from Hardware Direct, you can be sure that:
- You are buying a server from an official Dell partner with professional server hardware service
- The server is sold with a premium Next Business Day service contract. In case of failure, we are the first to deliver replacement hardware to you. More details in the corresponding tab.
ATTENTION!
Photos are for reference only, some elements of the server configuration such as risers may differ from those shown in the photos.
Specifications
| Manufacturer | |
|---|---|
| Condition | Refurbished |
